Anyone with KNS pins - PLEASE READ

Z06

UZI Talk Life Member
Feedback: 12 / 0 / 0
Joined
Mar 2, 2003
Messages
3,838
Location
AZ
Chris @ KNS emailed me recently regarding a picture I had posted of my 9mm M16 setup. He said I should REALLY upgrade my Gen 1 KNS pins to the Gen 2 Mod 2 set. He said to see him at the upcoming (Jan) S.H.O.T. Show in Las Vegas. I picked up a set of the Gen 2s and came home and installed them ASAP. Chris offers this upgrade for only $20... CHEAP insurance for RRs or any AR/M16 lower. Just a heads up.


MrM4

FFL 07/02, UZI Talk Life Member,
Feedback: 81 / 0 / 0
Joined
Jan 24, 2008
Messages
6,895
Location
Western South Dakota
Ive got sets of both, i fail to see why the "upgrade" is needed. Both are good products.

Did he give you a reason why he was recommending the "upgrade"?


Z06

UZI Talk Life Member
Feedback: 12 / 0 / 0
Joined
Mar 2, 2003
Messages
3,838
Location
AZ
Gen 1s have been know to break, un-ramped bolt 9mm uppers most often the cause. Gen 2 Mod 2 much stronger. Ramping still recommended. RR holes can get egged when pins are broken. Chris will probably come on here and correct my answer. I hope.


John C

UZI Talk Supporter
Feedback: 14 / 0 / 0
Joined
Aug 18, 2004
Messages
558
Some of the pins in the earlier models (mine included) were breaking at the oil hole. This occured because the oil holes were drilled thru the threaded section of the pin which weakened the pin there. KNS moved the oil holes a little further inboard and out of the threaded area. No problems with mine so far.

John C in PA


trek45

Well-known member
Feedback: 1 / 0 / 0
Joined
Feb 11, 2009
Messages
322
Yeah, seems a little strange to say you should upgrade if they don't explain why.


KNS_Chris

UZI Talk Life Member
Feedback: 0 / 0 / 0
Joined
Aug 9, 2007
Messages
22
John C said:
Some of the pins in the earlier models (mine included) were breaking at the oil hole. This occured because the oil holes were drilled thru the threaded section of the pin which weakened the pin there. KNS moved the oil holes a little further inboard and out of the threaded area. No problems with mine so far.

John C in PA

John, You are correct about the oil holes in the trigger pins. We also made the Hammer pin solid on all of the Gen 2 series pin sets. They are over 40% stronger than the Gen 1 pins. The Gen 1 pins are already stronger than the stock pins. We recommend anyone with an running 9mm or a Registered M-16 to upgrade. We gave away the upgrades for almost 2 years before we had to start charging for them. Email me if you have any questions.

Chris


MrM4

FFL 07/02, UZI Talk Life Member,
Feedback: 81 / 0 / 0
Joined
Jan 24, 2008
Messages
6,895
Location
Western South Dakota
thats interesting to know, wish i had know about the exchange program before but I've had great luck with my gen 1 pins so far.


javelinadave

UZI Talk Supporter
Feedback: 11 / 0 / 0
Joined
Jun 10, 2005
Messages
771
Location
AZ
I thought the Gen 1 pins were to prevent what they are saying the Gen 2 pins are for. Does Obama make these pins? My Gen 1's have been used for thousands of rounds. Anybody have one break yet?


MarkV

Well-known member
Feedback: 4 / 0 / 0
Joined
Nov 11, 2007
Messages
563
been using the gen 2 pins for the past three or four years. the gen 2 hammer pin is definitely stronger than gen 1 hammer pin. less hardware & no threads in the hammer pin. only issue i had was i had to radius the underside of the retaining pins near bolt release in order fit flush next to the mag well. since i use a lighter hammer spring for my 22 upper this keeps the trigger pin from walking when shooting 9mm & .223.


KNS_Chris

UZI Talk Life Member
Feedback: 0 / 0 / 0
Joined
Aug 9, 2007
Messages
22
javelinadave said:
I thought the Gen 1 pins were to prevent what they are saying the Gen 2 pins are for. Does Obama make these pins? My Gen 1's have been used for thousands of rounds. Anybody have one break yet?


We had 14 breakages. 13 in 9mm 1 in .223 suppressed. All have been covered by our lifetime warranty. We gave away thousands of upgrades for free. We had to stop because people were getting the free upgrades and then trying to get us to send out replacement trigger pins to get a free complete set.

I think if you talk to the people that have dealt with us for years, they can vouch for our integrity, honesty, and customer service. You may feel that those things represent Obama, but I respectfully disagree!!!

Chris


AZ Doug

UZI Talk Life Member
Feedback: 5 / 0 / 0
Joined
May 8, 2006
Messages
2,667
I received replacements for both my sets. My few dealings with KNS have been pleasant. It is unfortunate some took advantage of the replacement program.

No matter how much testing you do something can happen when the product is placed into production and installed on such a variety of guns. There is no way to test for every gun, cartridge... combination. What matters is how the company responds to it.

I think I learned of the upgrade on this forum when they were first released, possibly from one of VegasSMG's posts.


mikeyp

Member
Feedback: 0 / 0 / 0
Joined
Jan 2, 2010
Messages
12
your post

HAHAHAH.. I love the quote!.. I had problems with my KNS sear pin..I bought at Brownells.. I have a Frankfort M16...I could not get it to fit and It was the smallest they offer? I don't know why?
